Soundsmith Zephyr MIMC

Sale price2 250,00 €

Zephyr MIMC ☆

New ES Series DEMS design : Click to learn more about these cartridges!



Another positive review of the MIMC Star, at Positive Feedback " Listening to the music using this pickup is incredibly enjoyable. Zephyr also has incredible dynamics. "

Luxury You Can Afford (for the full review: click this)

Watch on YouTube

Also available in dual-coil mono.

Warranty

Workmanship on this product is warranted for 2 full years

Specifications

Cartridge Type

Fixed Coil

Stylus Type

Contact Line

Output

Low

Output Voltage

.4 mV

Available As Dual Coil Mono

Yes

Additional Specifications




Type: • Fixed Coil / Moving Iron
Mount: • Standard ½”
Stylus: • Selected Contact Line low mass Nude Stylus
Radius of Curvature: • 6 x 17 µm
Cantilever: • Laser Drilled Sapphire
Recommended Tracking Force: • 1.8 - 2.2 g
Effective Tip Mass: • 0.32 mg
Compliance: • 10 µm/mN
Frequence Response: • 15 - 45,000 Hz ± 2.0 dB
Channel Separation @ 1000 Hz: • > 28 dB
• N/A (Mono version)
Channel Separation @ 50 - 15,000 Hz: • > 25 dB
• N/A (Mono version)
Channel Difference: • < 1.0 dB
• < 0.5 dB (Dual Mono w/optimal VTF setting)
Output Voltage @ 5cm/sec: • > 0.40 mV (LOW)
DC Resistance (DCR): • 10Ω
Coil Inductance per channel: • 2.75 mH
Suggested Preamp Gain: • 58 - 64 dB
Cartridge Weight: • 12.2 g (ES series)
Recommended Load Resistance: • ≥ 470Ω
Recommended Load Capacitance: • n/a

All Info: Click to Download

All Info: (Mono Version) Click to Download
